BITHERM INTELLIGENT STEAM TRAP: STEAM SAVINGS 10% TO 20%.

CO2 EMISSIONS REDUCTION: 3% TO 6%.

¡Welcome to BiTherm!

Where innovation and experience meet efficiency

The intelligent steam trap patented by BiTherm in 1996 achieves an impressive 10% to 20% reduction in steam consumption, minimizes maintenance, maximizes reliability and optimizes operating costs.

BiTherm: Where every drop of steam counts!

Are you looking for innovative solutions to improve your plant’s energy efficiency and reduce your CO2 emissions? In our team of experts, not only … but also we are leaders in the design of energy-efficient smart traps and steam traps.

Not only do we offer energy-efficient smart traps and steam traps, but we also provide monitoring and customized energy efficiency solutions to meet each customer’s unique needs.

At BiTherm, we not only take pride in designing innovative solutions for energy efficiency, but also in helping our customers reduce their carbon footprint. With our smart traps, we have reduced CO2 emissions by 3% to 6%, which is a great achievement for us and our customers.

Don’t miss out on the opportunity to reduce your operating costs and lower your carbon footprint!

Contact us today to learn more about our energy efficiency solutions and how we can help you reach your goals.

¡BiTherm is a symbol of PRESTIGE!!

Its monitoring system is the most awarded in the world



Gold Medal

32nd International Exhibition of Inventions of Geneva (Switzerland).

April 2004

Jury’s Special Mention

32nd International Exhibition of Inventions Geneva (Switzerland).

April 2004

García Cabrerizo Foundation Award

García Cabrerizo Foundation Award for Spanish invention.

May 2004



Gold Medal

33rd International Exhibition of Inventions of Geneva (Switzerland).

May 2005



Gold Medal

40th International Exhibition of Inventions of Geneva (Switzerland).

April 2012



Excellence in Automation Award Winner

ISA100 Wireless Compilance Institute ILBOC Project

USA 2019



Winner in modality

I+D+i FOR A SUSTAINABILITY.

December 2023

BiTherm stands for INNOVATION, MAXIMUM PERFORMANCE

and offers the most complete range of options available on the market

EVOLUTION OF BITHERM STEAM TRAP MONITORING SYSTEM

The following diagram describes the evolution of the BITHERM Steam Trap Monitoring System since 1996:

Imagen 1

  • Architecture: Optical (Solar powered with rechargeable battery)
  • Topology: One-to-One
  • Local alarm by red LED flashes
Imagen 2

  • Architecture: Cable Bus RS-485
  • Topology: Multidrop (up to 64 devices with 4 channels/device) per cable
  • Maximum cable bus length: 1,200 meters (2,400 meters with bus extender)
Imagen 2

  • Architecture: Wireless (Zigbee) (battery powered)
  • Topology: Star (One-to-One)
  • One wireless sensor-transmitter, with, per steam trap or valve
Imagen 2

  • Architecture: Wireless ISA100 11a (battery powered)
  • Topology: Star (One-to-One)
  • One wireless sensor-transmitter, with battery, per steam trap or valve
Imagen 2

  • Architecture: Cluster Cable-Wireless ISA 100 11a (Solar rechargeable battery)
  • Topology: Cluster up to 20 sensor devices, without battery, per transmitter
  • One wireless transmitter, with solar rechargeavle battery, per cluster
Imagen 2

  • State-of-the-Art on Gas Leak Detection & Monitoring for PZVs & On-Off Valves
  • Architecture: Wireless LoRa/LTE-(NB-IoT) (battery powered)
  • Topology: Star/Mesh One-to-One
  • One sensor-transmitter device, with battery, per valve or steam trap
Imagen 2

  • State-of-the-Art on Gas Leak Detection & Monitoring for Steam Traps
  • Architecture: Cluster Cable-Wireless Lora/LTE (NB-IoT) (Solar energy powered)
  • Topology: Cluster up to 20 sensor devices, without battery, per transmitter
  • One wireless transmitter, with solar rechargeavle battery, per cluster

¡BiTherm guarantees MAXIMUM QUALITY!

It’s monitoring devices are manufactured in AISI 316L stainless steel.

Our Vision



Our vision is to lead the intelligent solutions sector in order to provide solutions of great value to society.

Our Solutions



We provide excellence in technology, innovative solutions, quality and experience backed by excellent results and strong benefits for our customers.

Our Mission



To meet the expectations of our customers. We are committed to a policy of Social Responsibility with a firm commitment to sustainable growth, respectful of the environment, training, health and safety.

Slide 2
BITERMOSTATIC STEAM TRAP

It is the ideal trap for monitoring, since its external adjustment mechanism allows to modify its condensate discharge temperature. One notable feature is that it allows any service incident to be resolved without the need to interrupt its operation. Likewise, its maintenance is carried out online and, even more so, without the need for spare parts. Consequently, the Bitherm bithermostatic trap is an essential element in monitoring.

The bithermostatic steam trap also stands out for its construction and robustness. In addition, its valve is covered by a layer of Titanium / Aluminum Nitride of extreme hardness and resistance to erosion wear. As a result, its durability is three times the service life of a conventional bimetallic trap.

Finally, its full port balanced pressure valve allows it to operate with minimal differential pressure. Thanks to its external adjustment mechanism, the bithermostatic steam trap adapts to a wide variety of service conditions. Although it is manufactured in series, thanks to its special design, it behaves like a drain specifically designed for each application.

Slide 3
ADVANTAGES OF USING OUR INTELLIGENT STEAM TRAP

The Bitherm SmartWatchWeb™ smart trap is the most advanced solution to achieve the following objectives in steam networks:
– Failure rate in drains
– Steam leak rate in traps
– Maximum efficiency and reliability
– Minimum CO2 emission
– Minimum maintenance cost

These objectives are only achieved by applying the Intensive Maintenance Methodology.
Note that monitoring of drains is a necessary condition to obtain all these benefits, but not sufficient. Indeed, it is not enough to detect incidents; It is necessary to correct them immediately to obtain these benefits. This is precisely what Intensive Maintenance consists of.

Well, first of all, the Bitherm SmartWatchWeb™ intelligent drain detects any mechanical, electronic, operational incident, etc., in real time. Additionally, it is designed to correct them online and in service. As a result, the Bitherm SmartWatchWeb smart drain is the most advanced, efficient and cost-effective solution currently available. Likewise, it is the proven solution with the most experience and references over more than 20 years in refineries, petrochemicals,…

The smart drain also provides enormous value and is essential in the digitalization of drains. This achieves effective integration and profitability of the drain in the production processes in the industry.

previous arrowprevious arrow
next arrownext arrow

BiTherm is a guarantee of service!

It is the monitoring system with the most references in the world.

(More than 100 process plants with more than 35,000 steam traps and monitored valves)

BITHERM SmartWatchWeb ™ STEAM TRAP MONITORING SYSTEM

CUSTOMER / ENGINEERINGPROJECTCOUNTRY
IBERIAN LUBE BASES OIL COMPANYALL THEIR STEAM TRAPSSPAIN
CEPSA REFINERYDESULFURATION UNIT 1SPAIN
CEPSA REFINERYDESULFURATION UNIT 2SPAIN
CEPSA REFINERYUNIT AREA 7SPAIN
CEPSA REFINERYPIPE RACKS & TANKS AREASPAIN
CEPSA PARQUE ENERGÉTICO LA RÁBIDAMMyD AREASPAIN
PETRONOR REFINERYASPHALT UNITSPAIN
PETRONOR REFINERYDESULFURATION SR3SPAIN
PETRONOR REFINERYDESULFURATION SR4SPAIN
PETRONOR REFINERYDESULFURATION SR5SPAIN
PETRONOR REFINERYDESULFURATION SR6SPAIN
PETRONOR REFINERYVACUUM DISTILLATION UNIT V3SPAIN
PETRONOR REFINERYCOCKE UNIT CK6SPAIN
REPSOL-PUERTOLLANO REFINERYDESULFURATION UNIT 639SPAIN
REPSOL-PUERTOLLANO REFINERYDESULFURATION UNIT 644SPAIN
REPSOL-PUERTOLLANO REFINERYDESULFURATION UNIT 621SPAIN
REPSOL-PUERTOLLANO REFINERYDESULFURATION UNIT 639SPAIN
REPSOL-PUERTOLLANO REFINERYDESULFURATION UNIT 639SPAIN
REPSOL-PUERTOLLANO REFINERYVACUUM DISTILLATION UNIT 624SPAIN
REPSOL-PUERTOLLANO REFINERYCOCKE UNIT 641SPAIN
REPSOL-PUERTOLLANO REFINERYOLEFIN UNIT 810SPAIN
REPSOL-PUERTOLLANO REFINERYNEMZEME UNIT 810SPAIN
REPSOL-PUERTOLLANO REFINERYLUBRICANTS UNIT 701SPAIN
REPSOL-PUERTOLLANO REFINERYLUBRICANTS UNIT 710SPAIN
REPSOL-PUERTOLLANO REFINERYLUBRICANTS UNIT 720SPAIN
REPSOL-PUERTOLLANO REFINERYLUBRICANTS UNIT 721SPAIN
REPSOL-PUERTOLLANO REFINERYLUBRICANTS UNIT 731SPAIN
CHUPACHUPSALL THEIR STEAM TRAPSSPAIN
REPSOL-CARTAGENA REFINERYDEASPHALTED 2 - UNIT 751SPAIN
REPSOL-CARTAGENA REFINERYFURFURAL 3 - UNIT 752SPAIN
REPSOL-CARTAGENA REFINERYDEWAXING 3 - UNIT 753SPAIN
REPSOL-CARTAGENA REFINERYVACUUM 4 - UNIT 754SPAIN
REPSOL-CARTAGENA REFINERYDESULFURATION UNIT - 685SPAIN
REPSOL-CORUÑA REFINERYCOCKE UNIT 1303SPAIN
REPSOL-CORUÑA REFINERYVACUUM DISTILLATION 2 UNIT 1301SPAIN
REPSOL-CORUÑA REFINERYPRA 3 UNIT 1220SPAIN
REPSOL-CORUÑA REFINERYPRA 4 UNIT 1314SPAIN
REPSOL-CORUÑA REFINERYCRUDE 1 UNIT 1201SPAIN
REPSOL-CORUÑA REFINERYVACUUM DISTILLATION 1 UNIT 1203SPAIN
REPSOL-CORUÑA REFINERYPLATFORMING 1 UNIT 1204SPAIN
REPSOL-CORUÑA REFINERYGASES 1 UNIT 1206SPAIN
REPSOL-CORUÑA REFINERYDEASPHALT UNITSPAIN
REPSOL-CORUÑA REFINERYFCC UNITSPAIN
TANAJIB/BITHERMRASTANURA UNIT J06 (HYDROGENE)SAUDI ARABIA
SAUDI ARAMCO/TECNICAS REUNIDASJAZAN JIGCC UTILITIESSAUDI ARABIA
SAUDI ARAMCO/SNAMPROGETTIPK2 JAZAN UTILITIES JIGCCSAUDI ARABIA
SAUDI ARAMCO/SAIPEMPK1 JAZAN UTILITIES JIGCCSAUDI ARABIA
TANAJIB/HYUNDAI ARABIA LLCJAZAN (SAUDI ARAMCO)SAUDI ARABIA
SAUDI ARAMCO/TECNICAS REUNIDASJIGCC UTILITIES COMMON AREA PACK 5SAUDI ARABIA
SAUDI ARAMCO/HYUNDAITANK FARM JAZANSAUDI ARABIA
SAUDI ARAMCO/HYUNDAIJAZAN REFINERY & TERMINAL EPC 2SAUDI ARABIA
SAUDI ARAMCO/TECNICAS REUNIDASJAZAN REFINERY & TERMINAL PROJECTSAUDI ARABIA
SAUDI ARAMCO/HYUNDAIJAZAN REFINERY & TERMINAL EPC PROJECTSAUDI ARABIA
SAUDI ARAMCO/TECNICAS REUNIDASMARJAN GAS PLANT PROJECTSAUDI ARABIA
SAUDI ARAMCO/HYUNDAIMARJAN GAS PLANT PROJECTSAUDI ARABIA
ANCAP-REFINERÍA LA TEJAALL STEAM TRAPS IN THE REFINERYURUGUAY

CONTACT US

For technical assistance on steam traps and steam traps, energy efficiency projects, BASE LINE evaluation of potential savings, operational problems in steam installations, … click on the following button.

WHERE WE ARE

We provide specialized services focused on excellence in energy efficiency of steam networks in the oil refining and petrochemical industry sectors. Our technicians are highly qualified professionals with decades of experience, backed by excellent results.
